Detailed Specifications
System Specifications
ProcessorRK3588, Octa-Core, 4*Cortex-A76 and 4*Cortex-A55, 2.4GHz, 1.8GHzMicrophoneSingle Mic
ButtonsPower, Volume+/-, Home, Custom Key, FuncionesMemory4GB(optional 8GB)
LED Indicatorcharging LEDStorage64GB(optional 32GB/16GB)EMMC; 1*M.2 NVME SSD
SensorG-SensorCamerafront 5MP fixed-focus Camera; Rear 13MP auto-focus Camera
SpeakerMono Speaker, 1W/8ΩAluminum Film, IP65waterproof
Display
Display10" IPS LCDTouchscreen5-Point Capacitive Touch
Resolution1920*1200Glass PanelCorning Gorilla Glass 3, hardness 7H, light transmittance 85%
Brightness750cd/m2
Operating System
Operating SystemAndroid 12, Linux (Ubuntu, Debian)POGO PIN1*POGO PIN
LAN1*RJ45USB1*USB Type-C 1*USB 3.0, Type-A
COM Port1*RS232SIM Card Slot1*Micro SIM slot
Video1*mini HDMITF Card Slot1*TF slot
Audio3.5 mm headphone jackAviation ConnectorExpansion: 1*RS232 / 1*DC / 1*LAN(100M) / 1*USB2.0
DC Jack1*DC Jack
Wireless Communication
4G(Optional)GSM: B3/B8 WCDMA: B1/B8 LTE-FDD: B1/B3/B7/B8/B20/B28AWiFiWiFi 5
BluetoothBluetooth 5.0GNSSGPS+Bei Dou
Expansion Features
NFC/RFIDoptional NFC/HF-RFID/UHF-RFID, one of three optionsBarcodeoptional 1D/2D barcode scanning
Power Specifications
Power Input19V/3.42A power adapterBattery4000 mAh, 11.4V
Environmental Specifications
Drop Resistance1.2m Wooden Floor, Free FallOperating Temperature-10℃～50℃
IP RatingIP65Storage Temperature-20～70℃(without battery)
Certifications
CertificationsCE, RoHS, UN38.3, MSDS, IEC62133, IPetc.
Physical Specifications
Dimensions (W x H x D)297.2*190.7*23.5mm optional UHF RFID module thickness+9.5mmWeight1.3kg
ColorBlack
Accessories
Accessorieshand strap, 19V/3.42A power adapterOptional Accessoriescharging Cradle, Type-C data cable, capacitive Pen
