Detailed Specifications
System Specifications
ProcessorMT6769, 2 ARM® Cortex-A75 2.0 GHz + 6 ARM® Cortex-A55 1.7 GHzMicrophoneIP67microphone waterproof
IP67waterproof ReceiverMemory6GB
ButtonsPower, Volume+/-, Custom Key, Scan KeyStorage64GB
LED Indicatorcharging LEDCameraFront 5MP fixed-focus Camera, Rear 13MP auto-focus Camera
SensorG-Sensor, Gyroscope, Proximity, Motor, Light Sensor, Barometric, Geomagnetic(optional)
SpeakerMono Speaker, 1W/8Ω Aluminum Film, IP67waterproof Speaker
Display
Display8" TFT-LCDTouchscreen5-Point Capacitive Touch, optional AG+AF+Wet Hand/Glove
Resolution800*1280Glass PanelCorning Gorilla Glass 3, hardness 7H, light transmittance 85%
Brightness500 cd/m2, optional 700/1000/1300 cd/m2
Operating System
Operating SystemAndroid 12
I/O Interfaces
POGO PIN1*POGO PIN(USB+charging)Audio3.5 mm headphone jack
USB1*USB Type-C(USB OTG+charging) 1*USB 2.0, Type-ATF Card Slot1*TF slot(max. 1 TB)
SIM Card Slot1*Micro SIM slotDC Jack1*DC Jack
Aviation ConnectorExpansion: 1*RS232 / 1*DC / 1*LAN(100M) / 1*USB2.04GGSM: B2/3/5/8 WCDMA: B1/2//5/8 CDMA: BC0 TDD: 34/38/39/40/41 FDD:1/3/5/7/8/20/26/28A/28B
WiFiWiFi 5 802.11(a/b/g/n/ac)BluetoothBluetooth 5.0
GNSSGPS/Bei Dou/GLONASS/Galileo
Expansion Features
NFC/RFIDoptional NFC/HF-RFID/UHF-RFID, one of three optionsBarcodeoptional 1D/2D barcode scanning, one of two options
Power Specifications
Power Input5 V / 3 A, 6Energy EfficiencyDCPort Adapter customizable: Power Input(DC 5~24 V, No Battery)Battery9800mAh, 3.8V high-capacity battery
Battery Life12h(LCD 100%brightness, video playback 1080p)
Environmental Specifications
Drop Resistance1.2m Wooden Floor, Free FallOperating Temperature-10℃～50℃
IP RatingStandard IP65, optional IP67Storage Temperature-30℃～70℃(without battery)
Certifications
CertificationsCE, RoHS, UN38.3, MSDS, FCC
Physical Specifications
Dimensions (W x H x D)227*142.4*22.9mm optional UHF RFIDthickness+9.5mmWeight0.80KG
ColorBlack
Accessories
AccessoriesStrapwith, Type-C OTG cable, 5 V / 3 A 6Energy EfficiencyDCPort AdapterOptional AccessoriesCradle, Vehicle Mount, vehicle charger, Passive Stylus, Type-C data cable, vehicle charger bracket
