Detailed Specifications
System Specifications
ProcessorIntel® Core™ i5-1135G7/i7-1165G7MicrophoneSingle Mic
Memory16GBButtonsPower, Volume+/-, Home, FKey2D, PKey
Storage256GB (optional 512GB/1T)LED Indicatorcharging LED
Camerafront 5MP fixed-focus Camera; Rear 13MP auto-focus CameraSensorG-Sensor, Geomagnetic
SpeakerMono Speaker, 1W/8ΩAluminum Film, IP67waterproof
Display
Display10.1" IPS LCDTouchscreen5-Point Capacitive Touch
Resolution1200*1920Glass PanelCorning Gorilla Glass 3, hardness 7H, light transmittance 90%
Brightnessdisplay750cd/m2, TPlight transmittance 90%
Operating System
Operating SystemWindows 10/11
I/O Interfaces
POGO PIN1*POGO PINLAN1*RJ45
USB1*USB Type-C; 1*USB 3.0, Type-ACOM Port1*RS232
SIM Card Slot1*Micro SIM slotVideo1*mini HDMI
TF Card Slot1*TF slot, max. 1 TBAudio3.5 mm headphone jack
Aviation ConnectorExpansion: 1*COM(RS232/485/422) / 1*USB2.0DC Jack1*DC Jack
5GWCDMA: B1/B3/B5/B6/B8/B19 LTE-TDD: B34/B38/B39/B40/B41/B42/B43 LTE-FDD: B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32 5G NR SA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/ n77/n78/n79 5G NR NS: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/ n77/n78/n79WiFiWiFi 6E, 2.4G+5G+6G
BluetoothBluetooth 5.3GNSSU-blox GPS+Bei Dou+GLONASS+Galileo
4Goptional(funciones 4G, No funciones 5G)
Expansion Features
RFIDoptional LF RFID/HF RFID/UHF RFIDBarcodeoptional 1D/2D barcode scanning(Honeywell N3680)
ID Recognitionoptional ID Card Recognition ModuleNFCStandard 13.56MHz, 14443A/14443B/ 15693
Fingerprintoptional(Standard, Fingerprint3000 x )Power Input19V/3.42A power adapter
Battery Lifebattery life3.5h,Battery 0.5h(LCD 100%brightness, video playback 1080p)Battery4000 mAh, 11.4V +2000mAh,7.6V, Battery
Environmental Specifications
Drop Resistance1.2m Wooden Floor, Free FallOperating Temperature-10℃～50℃(-30℃optional)
IP RatingIP65Storage Temperature-20℃～70℃(without battery)
Certifications
CertificationsCE, RoHS, UN38.3, MSDS, IEC62133, IPetc., FCC
Physical Specifications
Dimensions (W x H x D)297.2*190.7*23.5mm optional UHF RFID module thickness+9.5mmWeight1.35kg
ColorBlack
Accessories
Accessorieshand strap, 19V/3.42A power adapterOptional Accessoriescharging Cradle, Type-C data cable, capacitive Pen
